Insulated Pipe Support – Heavy Duty with Load Bearing Plate – A7400
General Dimensions & Specifications
Note: For higher load ratings, see B1200
| Pipe Size |
MAXIMUM LOAD RTG. (LBS)On Flat Surface (a) |
A | B | C |
|---|---|---|---|---|
| 10 | 2100 | 9 | 6 | 3/4 |
| 12 | 3400 | 9 | 6 | 3/4 |
| 14 | 3900 | 9 | 6 | 3/4 |
| 16 | 4400 | 9 | 6 | 1 |
| 18 | 4800 | 9 | 6 | 1 |
| 20 | 5100 | 9 | 6 | 1 |
| 24 | 5500 | 9 | 6 | 1 |
| 30 | 5500 | 9 | 6 | 1 |
| 36 | 6500 | 9 | 6 | 1 |
| 42 | 7500 | 9 | 6 | 1 |
| TABLE I | ||||
Contact factory for other dimensions, temperatures, and loads.
Available in all insulation thicknesses.
The load ratings represent average values obtained in accordance with accepted test methods and are subject to normal manufacturing variations. Dimensions and ratings are subject to change without notice. Contact factory for current information.
a) To develop maximum load rating, width of support sur face should be at least 1/2 of dimension “B” in Table I.
Application:
Model A7400 is designed for use on:
- Hot water | Steam
- Cold water | Air
- Chilled water | Gas
- Dual temperature | Vacuum
Intended for installation on:
- Flat surfaces
- Pipe rolls, see A8400
- Clevis hangers, see A9000
Temperature Range:
Standard: +40°F to +1200°F CalSil Insulation
Note: Up to 1800°F available upon request.
Cryogenic: -275°F to +275°F Urethane Insulation.
Add U after the model number (i.e., A7400U)
Features:
- Compact
- Easy installation
- Eliminates welding to pipe
- Copper tubing sizes available
- Minimizes heat-loss and/or condensation
- Insulating structural inserts for load transfer
- Overlapping galvanized sheet metal jacket
- Load distribution plate integral with bottom jacket
- Other I.D.’s and/or O.D.’s available on request
Performance test results on file:
Available upon request
Material Data:
- A7400:
Applicable PSI spec. doc.: No. 205 - Insulation:
Calcium silicate asbestos-free,
treated with water repellant - Jackets:
Galvanized steel ASTM A-653 - Structural Inserts: High-density calcium
silicate asbestos-free, treated with water
repellant - Load distribution Plate:
Carbon steel ASTM A-36 - Coating:
Primer coated or hot-dip galvanized
Other coatings available upon request - Glue:
Industrial contact adhesive
Formal submittal sheets available
